The LM940AT is a small non-pressure precision molding plate and is a small hot press equipment with excellent uniform temperature,
pressure maintenance, and plate horizontality.
It is a device that can be custom-made according to options such as high-precision LM Guidance Rail and vacuum plates,
and control pressure through load cells for special molding such as medical diagnostic kits, electrode material coating, and low-pressure hot melting.
※ This product is a hot press, not a product subject to autonomous safety certification under the Industrial Safety and Health Act.
| Detail of QM940AT
Specifications
| MODEL | LM940AS (전극용) | LM940AS (일반형) | LM940A-T | ||
|---|---|---|---|---|---|
| Temp. Range | RT ~ 250℃ | ||||
| Pressure | Max. 2.5t (Air input 8kgf/㎠) | Max. 2.5t (Air input 8kgf/㎠) | Max. 0.6t (Air input 8kgf/㎠) | ||
| Pressure System | Air Cylinder System | ||||
| Plate Size | 100 x 100mm (Teflon Coating) | 200 x 200mm | 200 x 200mm | ||
| Cooling System | Natural Cooling | ||||
| Dimensions | 650(W) x 810(D) x 1750(H)mm | 650(W) x 810(D) x 1750(H)mm | 500(W) x 450(D) x 1100(H)mm | ||
