IZOD Digital Impact Tester

LM750A

Product Features

● Dual Test (IZOD&CHARPY)
● High Definition Optical Encoder
● Energy Dispersion Protection Structural Design
● Electromagnetic measurement system
● Composite multi-safety system functionality
● Automatic unit conversion and measurement data report output





The LM750A is an impact tester that can be used by adjusting the Izod and Charpy impact acceleration (Accuracy ±0.02%) according

to ASTM and ISO test method, and can automatically measure the entire test process such as Auto Rising and Auto Braking system.

High precision optical digital encoders and enhanced safety, dual safety locks and safety door systems provide the best precision

and safety required for measurement.


      ■ Standard :  ASTM D 256, ISO 180, ISO 179


| Digital Indicator QUATRO-300



● 10" Color LCD Display & Safety Button

● First Guide Map in Korea

● Automatic calibration & automatic unit conversion (6 types)

● Automatically save data (Max.200Ea)



Specifications

MODEL LM750A (IZOD) LM750A (CHARPY) LM750B (Bonding Impact)
Test Method IZOD CHARPY Bonding Impact
Capacity 2.75J/5.5J 5J or 10J 5J or 10J
Angle of Hammer 150˚ 130˚ 150˚
Angle Resolution ± 0.1˚
Velocity 3.5m/sec ±1% 2.9m/sec ±1% 3.5m/sec ±1%
Standard ASTM D 256, ISO 180 ISO 179 ASTM D 950
Dimensions 930(W) x 330(D) x 810(H)mm
