Universal Testing Machine

LM100T

Product Features

● Only for large-capacity load test (plastic, composite material, carbon, aluminum, steel)
● Best-in-class axial distance (460–660 mm)
● High Load Overload Safety System Application
● Various options (grip, extensometer, strain gauge, environmental chamber, safety box)





LM100T is a universal material tester that can analyze high-precision physical properties of various materials from 2000Kgf to up to 20000Kgf.

As the most suitable equipment for testing plastic composite materials, various strength, elongation, and modulus can be automatically measured

by selecting tensile, compression, bending, elongation, and environmental chamber, which are essential items in the engineering plastic field.

High-performance Servo Motor, Damping-Resistance System, and dedicated Software (Q-Pro3.1) implement high-precision control

and multiple safety systems without shaking even in high-load tests, which can efficiently measure and analyze changes in high-capacity specific physical properties.

In particular, the high-capacity Wedge Grip can be tested by shape of various materials such as carbon, aramid, steel, aluminum, and bolt,

and provides the best solution for test measurement, fast delivery, reasonable price, and good quietness.


| Digital Indicator QUATRO-100



● CE Certification
● High-speed, high-precision data measurement (Raw Data 180-240p/sec)
● Equipped with a high-precision Micro CPU (1/10,000 resolution)
● Standalone Controllers
● Built-in autonomous safety features
● Test speed storage and automatic test function
● Strain gauge expansion port (Option)



| Software Q-Pro 3.1



● Support for various tests
    (tension, tear, peeling, compression, bending, hardness, friction, repetition, maintenance, hardness test, etc.)
● Convenient sample information input function
    (automatic cross-sectional operation, continuous test measurement, automatic unit conversion, etc.)
● Various test speed settings (distance speed, load speed, multi-section speed, etc.)
● Data editing functions (excel support, parameter editing, raw data numerical view, interval setting, etc.)
● Real-time monitoring (communication, overload, safety, measurement)
● Remote Control Diagnostics and Remote Training Support
● Extensometer, strain gauge, and environmental chamber interlocking function




Test Method



Application





Specifications

MODEL LM100TS LM100TM LM100T
Capacity 100, 200, 500 Kgf 100, 200, 500, 1000Kgf 1, 2, 5, 10, 20, 30t
Crosshead Speed 0.1 ~ 600mm/min
Availability Travel (Non Grip) 500mm 950mm 1100mm
Operating Travel 400mm (Excluding Compression Grip) 750mm (Excluding One-touch Grip) 650mm (Excluding Wedge Grip)
Distance from the Columns 350mm 450mm 460mm
Indicator 7" Color LCD Touch Screen LCD Graphic Display LCD Graphic Display
Raw Data 50 ~ 120p/sec 150 ~ 240p/sec
Load Resolution < 0.05% < 0.02%
Safety Device Emergency S/W, Stroke & Load Limit, UP/Down Limit, Auto & Return Set Memory, Data Output (RS232C Type)
Dimensions 635(W) x 385(D) x1115(H)mm 750(W) x 450(D) x 1590(H)mm 800(W) x 600(D) x 1880(H)mm
