Home > PRODUCT > Flammability Tester
LM500V is a flame-retardant tester that is convenient to maintain the combustion distance between flame and material
by applying a 9.5mm Bunsen burner (USA) and an automatic vertical transfer system as cited flame-retardant test equipment based on UL 94.
Vertical tests 94V-0, 94V-1 and 94-5V tests can be similarly measured.
■ STANDARD : UL 94V-0, 94V-1, 94V-2, 94V-5VA(20°)
Specifications
| MODEL | LM500H | LM500D | LM500V | LM500HWF | LM500U |
|---|---|---|---|---|---|
| Burner | Bunsen Burner | Mackell Burner (Option : Air-Mix Burner) | Bunsen Burner | Wing Burner | Bunsen Burner |
| Burner Sliding | Fixed | Fixed | Auto(Up, Down) Manual(Left, Right) | Manual(Left, Right) | Auto(Up, Down) Manual(Left, Right) |
| Test Angle | 90° | 45° | 20°, 90° | 15°, 90° | 20°, 45°, 90° |
| Standard | FMVSS 302, MS300 | KS K 2619,K 0770 | UL-94 | ISO 9772, ASTM D 1692 | UL 94, ASTM D 635 |
| Dimensions(In) | 380 x 200 x 340mm | 380 x 250 x 500mm | 420 x 375 x 800mm | 1000 x 550 x 1000mm | 1000 x 550 x 1000mm |
| Dimensions(Out) | 480 x 280 x 630mm | 780 x 420 x 800mm | 1025 x 400 x 820mm | 1200 x 820 x 2100mm | 1200 x 820 x 2100mm |
